进口潜水搅拌机_德国进口污泥搅拌机

产品简介：

产品详情：导入潜水搅拌机-格林巴赫 BH.格林巴赫潜水调音台介绍： 产品称呼：混合潜水搅拌器QJB型潜水搅拌机可以分成两个系列：混合和低速推流。 混合系列混合机适用于在污水处理厂和工业过程中混合带有悬浮固体的液体； 低速推流系列搅拌机适用于工业和城市污水处理厂的曝气池。它们产生低的切向流强水流，可用于在循环，硝化，反硝化和除磷等阶段产生水流。 bh。适用范围： 调音台应能够在以下条件下正常连续运转： 1介质温度不超过40°c； 2介质的PH值在5〜9之间； 3液体密度不超过1150kg/m3； 4长期潜水作业，潜水深度一般不超过20m。 bh。关键的提示： 潜水搅拌机必须全然浸泡水中才能工作；不能在有着易燃，易爆或强腐蚀性液体的环境中工作；钢膨胀螺栓必须根据要求开展固定，并且安装后必须拧紧并固定电线。 潜水推流器选项种类时，如果叶片直径超过2m，提议使用齿轮减速器。 bh。特点： ◆构造连贯，操作维护简便，安装维护便利，使用寿命长； ◆叶轮使用油压设计构造，工作效率高，后掠式叶片有着自洁机能，防止杂物缠结和堵塞； ◆与曝气系统混合使用，可大大减低能耗，显着增加氧合，有效防止沉淀； ◆电机绕组的绝缘等级为f，保护等级为IP68。选项滚珠轴承和电机防凝露装置可以使马达的工作更安全； ◆两个机器密封； 电机绕组为f级绝缘，防护等级为ip68，与污水处理厂的曝气系统配合使用，可大大下降系统的能耗，并显着提高充氧能力，可以有效地防止沉淀。根据工艺要求，直接连通的潜水混合器可配置导流板。 潜水搅拌机主要用于市政和工业污水处理过程的混合，搅拌和循环。它也可以用于维护风景水环境。叶轮的旋转达到产生水流，提高水质并增加使用水的人的氧气含量的效果。有效防止悬浮固体的沉积。 为了满足在不同环境下可以实现的混合功用，我们为用户提供了各种型号的潜水搅拌器，还可以提供选型服务。 潜水搅拌机的安装位置对其混合效果有很大影响。为了达到倍增器的操作效果，提议用户遵循设计者的要求，并考虑池的形状，进水口和出水口的位置以及混合器的水流。反射到由构造引起的涡旋，最大限度地缩减短路循环和死角的产生，并避免与池壁相撞并缩减流量。 Introduction to BH. Greenbach submersible mixer： QJB submersible mixer can be divided into two series： mixing mixer and low speed plug flow mixer。 Mixing series mixer is suitable for mixing liquid containing suspended solids in sewage treatment plant and industrial process; Low speed plug flow mixer is suitable for aeration tanks of industrial and urban sewage treatment plants. It produces strong low tangential flow and can be used to create flow in circulation，nitrification， nitrogen and phosphorus removal stages。 bh。Scopeofapplication： The mixer shall be able to operate normally and continuously under the following conditions： 1. The maximum medium temperature shall not exceed40°c; The pH value of the medium is between 9 and5; 3. The liquid density shall not exceed 1150Kg /m3; 4. For long-term diving operation, the diving depth is generally less than 20m。 bh。Keypoints： The submersible mixer must fully submerge into the water; it can not work in the environment of flammable and explosive or corrosive liquid; the steel expansion bolt must be fixed according to the requirements, and the cable must be tightened and fixed after the installation When selecting submersible thruster, the blade diameter is more than 2m，so gearbox reduceris recommended bh。Features： It hascompactstructure，simple operation and maintenance, convenient installation and maintenance, and long service life; The impeller has the best hydraulic design structure and high working efficiency. The swept back blade has self-cleaning function, which can prevent impurities from winding and blocking; Mixing with aeration system can greatly reduce energy consumption, increase oxygen content and effectively prevent precipitation; The insulation grade of the motor winding is f, and the protection grade is IP68. High quality bearing and anti condensation device are selected to make the motor work safer; Twomechanicalseals; The motor winding is F-class insulation, and the protection grade is IP68. When used in the aeration system of sewage treatment plant, the energy consumption of the system can be greatly reduced, and the oxygen content can be significantly increased, which can effectively prevent precipitation. According to the process requirements, the direct connected submersible mixer can be equipped with a deflector。 The submersible mixer is mainly used for mixing, mixing and circulation in municipal and industrial wastewater treatment process, and can also be used for the maintenance of landscape water environment. It can create water flow through the rotating movementofimpeller，improvewater quality，increase oxygen content, and effectively prevent the deposition of suspended solids。 In order to achieve the best mixing function in different environments，we provide users with a variety of models of submersible mixers, and can provide selection service。 The installation and positioning of submersible mixer has a great impact on its mixing effect. In order to achieve twice the result with half the effort，we suggest users to do it according to the requirements of professional designers. We should fully consider the shape of the pool, the position of the inlet and outlet water, and the eddy current caused by the water flow reflected from the mixer to the structure，so as to minimize the short-circuit cycle and dead angle and avoid the leakage The impact with the pool wall reduces the flow velocity。
