进口蒸汽减压阀_欧洲品质进口减压阀

产品简介：

产品详情：进口蒸汽减压阀-欧洲质量巴赫制造 1.产品介绍： 蒸汽减压阀采用控制阀体内的启闭件的开度来调节介质流量，以降低介质压力。同时，启闭件的开度由阀门后面的压力调节，以将阀门后面的压力保持在一定范围内。在入口压力不停变动的情形下，请将出口压力保持在设定范围内，以保障后续的生产装置。 2.产品特性： 减压阀为先导活塞构造，内部设计使用多孔泄压方式，可大大增加气体流量，有效性扫除结冰状况，预防气蚀和气蚀影响节流通道，并延长产品使用寿命。 3.产品法则： 减压阀通过节流阀将进口压力降低到一定的出口压力，并保持出口压力安定。当减压阀出厂时，调节弹簧处于未压缩状况。此时，主阀盘和辅助阀盘处于关闭状况。采用时，顺时针转动调节螺丝以压缩调节弹簧，以使启闭件介质通过a孔。从阀座到孔b，它进入活塞上方。在介质压力的作用下，活塞向下移动以将主阀盘推离主阀座，从而使介质流到阀的背面，同时介质从孔c进入隔膜下方。。当阀后面的压力超过设定压力时，膜片将被向上促进以移动压缩调节弹簧，辅助阀盘沿关闭方向移动，从而使注入活塞上部的介质减小，并且当压力下滑时，主阀盘也会在主阀盘弹簧力的推动下上下移动，从而减小了主阀盘和主阀座之间的间隙，并且介质流量也减小了，因此，阀后的压力也降低到新的平衡，相反，当阀后的压力最低设定压力时，主阀盘和主阀座之间的间隙增加，介质流量也随之增加。增加，因此阀后的压力也增加到新的平衡。 4.性能参数： 公称直径：dn8〜dn50，输入气体压力可达到40mpa，很小输出压力可达到零压力，不仅可以降低动压，而且可以降低液压。 5.产品用处： 适用于工业供水，消防供水和生活用水管网系统。 1.Product简介： The steam pressure reducing valve is to control the opening of the opening and closing parts in the valve body to adjust the flow of the medium and reduce the pressure of the medium. At the same time，it can adjust the opening of the opening and closing parts with the help of the pressure behind the valve to keep the pressure behind the valve within a certain range. Under the condition of the constant change of the inlet pressure，it can keep the outlet pressure within the set range and protect the subsequent life and production appliances。 2.Productfeatures： The pressure reducing valve is a pilot piston type structure, which adopts the porous pressure relief design inside. It can greatly increase the gas flow, effectively eliminate the conditionsof icejam，prevent the influence of cavitation and cavitation on the throttling channel, and extend the service life of the product。 3.Productprinciple： The pressure reducing valve reduces the inlet pressure to a certain required outlet pressure by throttling the opening and closing parts, and keeps the outlet pressure stable. When the pressure reducing valve leaves the factory，the adjusting spring is in the uncompressed state, and the main valve disc and the auxiliary valve disc are in the closed state. When in use, turn the adjusting screw clockwise to compress the adjusting spring, so that the diaphragm disc moves to open the auxiliary valve disc， and the medium enters the piston from hole a through the auxiliary valve seat to hole B. under the actionofmedium pressure， the piston moves downward to push the main valve disc away from the main valve seat, so that the medium flows To the rear of the valve. At the same time，it enters into the lower part of the diaphragm through hole C. when the pressure behind the valve exceeds the set pressure，it pushes the diaphragm upward to compress the regulating spring, and the secondary valve disc moves to the closing direction，so that the medium flowing into the piston decreases and the pressure also decreases. At this time, the main valve disc moves up and down under the push of the spring force of the main valve disc，so that the gap between the main valve disc and the main valve seat decreases, and the medium flow also decreases On the contrary，when the pressure behind the valve is lower than the set pressure, the clearance between the main valve disc and the main valve seat increases, and the medium flow also increases，so that the pressure behind the valve increases to reach a new balance。 4.Performanceparameters： Nominaldiameter：DN8〜DN50， the maximum input gas pressure can reach40mpa， the minimum output pressure can reach zero pressure. It can reduce not only dynamic pressure but also static pressure。 5.Productuse： It is suitable for industrial water supply，fire water supply and domestic water pipe network system。 品牌介绍： 巴赫水泵有限公司（BACH）成立于1972年。 目前享有五个生产工厂（分布在英国和法国等国家）和27个泵销售分公司（分布在欧亚和其他32个国家）。自发展以来，公司已形成年产规模基于自动化生产的500万台以上泵（套），在工业泵行业中排名榜第一.30多年来，该公司始终致力于住宅建筑物用水泵的开发和生产。目前正在展开代理销售中国上海中的办公室。 意蝶阀门（上海）有限公司，对装置销售的长期承诺。 我们是巴赫BACH水泵的代理商！我们有很多巴赫库存，卧式多级离心泵，立式多级离心泵，家用增压泵，变频系统，卧式端吸泵，立式管道泵，静音屏蔽泵，热水循环泵，磁力泵，污水泵，所有进口水泵等。巴赫全系列水泵。我们是巴赫正规化代理商。我们经营的所有泵都是巴赫。在当今市场上，产品的优劣各有不同，我们将自始至终只制造高质量的产品。这是我们对公司的定位，也是对您的承诺。我们将用我们的行动验证：我们是您*准确的合作同伴！ 如需明白可以去我们公司： @每个@阀：
