商品信息
基本参数
- 产地上海
- 品牌
- 产品型号
- 产品操作
- 产品应用范围
- 产品材料等级
- 产品表面处理
- 品牌BACH
- 型号BHLG
- 叶轮数目单级
- 加工定制否
- 材质不锈钢
- 厂家BACH
产品简介：
产品详情：导入多级管道泵-@@@@
格林巴赫进口多级管道泵介绍：
巴赫泵采用垂直分段构造，泵的进，排气口底部设计成一条线，采用油压模型，泵的轴向力由水力抵消求解方式，残余轴向力由滚珠轴承背负，操作安定，噪声低，占地面积小，装饰方便。外筒由不锈钢制成，外观美观。特别适用于高层建筑中多台泵的并联使用，以减小单台泵的功率并简化电子控制装置，适用于消防，生活供水，空调机机组循环，冷却水住宅，诊所，酒吧，百货店，办公楼等的交付等
工作环境：
●用以运送清水或理化特性类似于清水的液体；
●输送液体中不理应固体微粒，纤维，强腐蚀性和爆炸凶险；
●液体温度不超过120℃；
●工作压力不超过2.5mpa；
●电源为三相380v，50hz。电压波动在±5％以内；
●环境温度应最低40℃，相对湿度应最低95％。
性能参数：
●流量：2-160m3/h；
●扬程：24-200m；
●功率：1.1-90kw；
●速度：2900r/min；
●光圈：φ25-φ150；
●温度范围：-15-+120℃；
●工作压力：≤2.5mpa
特点：
●有着占地面积小，泵的重点与泵脚中心重叠的特色，运行安定，振动小，寿命长。
●同一口径，同一程度中心线，不须变动管道构造，可直接安装在管道的任何部位，安装颇为方便。
●电机和防雨罩可直接在室外采用。
●通过变动泵级数（叶轮数）可以满足不同的扬程要求，适用范围广。
●轴封采用硬质合金机器密封，确实，无泄漏，机器损耗小。
Introductionof grinbach imported multistage pipeline pump：
Bachpump adopts vertical and segmented structure. The suction and discharge of the pump are designed in a straight line below, and the best hydraulic model is adopted. The axial force of the pumpissolvedby hydraulicbalancemethod， and the residual axial force is borne by a ball bearing，so the operation is stable, the noise is low, the floor area is small, and the decoration is convenient. The outer cylinder is madeofstainlesssteelwithbeautifulappearance，whichis especially suitable for the parallel use of multiple pumps in high-rise buildings，so as to reduce the power of single pump unit and simplify the electric control equipment. It is suitable for fire control，domesticwatersupply，air conditioning unit circulation and cooling water transmission of high-rise and low-rise buildings such as residences，hospitals，hotels，department stores and office buildings。
Workingconditions：
Used to transport clear water or liquid with physical and chemical properties similar to clear water;
There should be no solidparticles，nofibers，no strong corrosivity and no explosion risk in the transported liquid;
The maximum liquid temperature shall not exceed120℃;
The maximum working pressure shall not exceed2.5mpa;
The power supplyis 3-phase 380V，50 Hz. The voltage fluctuation is within±5％;
The ambient temperature should be lower than 40 ℃ and the relative humidity should be lower than95％。
Performanceparameters：
流量：2-160m3/ h;
●lift：24-200m；
功率：1.1-90kw;
Speed：2900r/ min;
Diameter：25- 150；
Temperaturerange：-15- +120℃；
Working pressure：≤2.5mpa
Productfeatures：
The center of gravity of the pump coincides with the center of the pump foot，so the operation is stable, the vibration is small, and the service life is long。
With the same caliber and on the same horizontal center line，it can be directly installed on any part of the pipeline without changing the pipeline structure, which is extremely convenient。
The motor with rain cover can be directly used outdoors。
The head can meet different requirements by changing the pump stage (impeller number），so it has a wide range of application。
The shaft seal adopts cemented carbide mechanical seal, with reliable seal，no leakage and small mechanical loss。
